machinery
Machines
CNC Womat M3
specifications
| table size | 3,300 x 1,000 mm |
| maximum stroke | x: 3,000 / Y: 1,000 / Z: 1,000 |
| maximum rotation | 3,000 RPM |
| permissible weight | 7,000 kg |
CNC Womat M1 L/1
specifications
| table size | 2,600 x 630 mm |
| maximum stroke | x: 1,800 / Y: 600 / Z: 500 |
| maximum rotation | 3,000 RPM |
| permissible weight | 7,000 kg |
CNC CHEVALIER
specifications
| table size | 3,100 x 1,450 mm |
| maximum stroke | x: 3,100 / Y: 1,500 / Z: 855 |
| maximum rotation | 6,000 RPM |
| permissible weight | 6,500 RPM |
CNC Hartford Machine
specifications
| table size | 6,000 x 2,500 mm |
| maximum stroke | x: 5,000 / Y: 2,600 / Z: 1,040 |
| maximum rotation | 6,000 RPM |
| permissible weight | 15,000 kg |
CNC FIL
specifications
| table size | 3,000 x 800 mm |
| maximum stroke | x: 2,500 / Y: 950 / Z: 1,200 |
| permissible weight | 4,000 kg |
CNC VMC 1000
specifications
| table size | 1,150 x 490 mm |
| maximum stroke | x: 1,200 / Y: 510 / Z: 500 |
| permissible weight | 900 kg |
fanuc wire EDM
specifications
| table size | 1,150 x 820 x 310 mm |
| maximum stroke | x: 600 / Y: 400 / Z: 310 |
| permissible weight | 500 kg |
Mazak 3d laser cutting
specifications
| table size | 3,500 x 2,000 mm |
| maximum stroke | x: 3,350 / Y: 1,545 / Z: 420 / A: 360° / B: 135° |
Okada Centro de Usinagem VDLS850
specifications
| table size | 1.000 x 500 mm |
| Travel | x: 860 / Y: 510 / Z: 560 |
| Rotation | 12.000 RPM |
| maximum weight | 500 kg |
Presetter Smile 320 Advance Zoller
specifications
| z measurement area | 350 mm |
| x measurement area | 160 mm |
| Ø | 320 mm |
| Ø pitchfork | 0 mm |
Tryout presses
DAN-PRESSE 630 T Hidráulica
specifications
| table size | 3,000 x 1,000 mm |
| maximum opening | 1,800 mm |
| maximum pressure | 630 T |
500 T KOMATSU Mecânica (2 unidades)
specifications
| table size | 3,500 x 2,500 mm |
| hammer stroke | 613 mm |
| maximum opening | 1,286 mm |
| hammer adjustment | 390 mm |
| strokes per minute | 18 |
| maximum pressure | 500 T |
Hidráulica 100 T
specifications
| table size | 500 x 500 mm |
| maximum opening | 500 mm |
| maximum pressure | 100 T |
Hidráulica 140 T
specifications
| table size | 1,000 x 840 mm |
| maximum opening | 900 mm |
| maximum pressure | 140 T |
Hidráulica 250 T
specifications
| table size | 3,000 x 1,600 mm |
| maximum opening | 2,500 mm |
| maximum pressure | 250 T |
Hidráulica 400 T
specifications
| table size | 600 x 1,800 mm |
| maximum opening | 1,400 mm |
| maximum pressure | 400 T |
1000 TON KOMATSU Mecânica
specifications
| table size | 4,570 x 2,440 mm |
| hammer stroke | 762 mm |
| maximum opening | 1,880 mm |
| strokes per minute | 12 |
| maximum pressure | 1,000 T |
Metrology
Braço Faro a Laser
specifications
| Alcance máximo | 3,000 mm |
| Software | CAM2 Measure10 / Polyworks |
Máquina tridimensional cmm coord3
specifications
| table size | 3,000 x 2,000 mm |
| Software | ARCOCAD |
| Curso Max | 1,875 x 1,400 x 1,000 mm |
Feeder / unwinder
Desbobinador e alimentador
specifications
| Desbobinador | 400 mm de largura. Endireitador até 4mm espessura. 3,000 kg max |
| Alimentador | 400 mm largura e PASSO 250 mm |
other machinery
Machine
| Clever |
| Pacific |
| Torno Romi |
| Torno Nardini |
| Retífica Cilíndrica |
| Retífica Plana |
table size
| - |
| - |
| Ø500 |
| Ø500 |
| Ø250 |
| - |
permissible weight
| 200 kg |
| 500 kg |
| - |
| - |
| - |
| 500 kg |
maximum stroke
| X: 600 / Y: 1,200 / Z: 500 |
| X: 400 / Y: 1,800 / Z: 500 |
| X: 1,500 |
| X: 1,500 |
| X: 1,000 |
| X: 500 / Y: 1,400 / Z: 400 |
